In Win 101C and Polaris RGB Fans review.

Packaging »

Introduction

In Win 101C and Polaris RGB Fans review. 101c, case fans, Cases, In Win, In Win 101c, In Win Polaris RGB, Mid Tower, polaris, Polaris RGB, RGB fans 1

Your case is the first thing people see when looking at your PC. However, it’s often the part of the system people put the least emphasis on since it has no effect on performance. This is true; however, it has a huge effect on the overall aesthetic of your build. With so many companies producing cases, it’s hard to know where to start. I usually recommend starting with a company that has a good reputation in the community. There are few companies that have that kind of reputation for beautiful, high-quality builds such as In Win, makers of the very popular 909. Most people equate In Win with expensive cases such as the D-Frame and the Winbot.  Although In Win is widely known for making some of the most unique, and expensive cases, they also make quite a few budget-oriented cases with the same style and quality In Win is known for.

We recently got our hands on the In Win 101C. This is a revised edition of their very popular In Win 101. They’ve added a USB 3.1 Type-C connector to the front panel of the case. This is a welcomed feature since many motherboards have integrated front panel USB Type-C controllers. Pair that with some of the features that made the original 101 so popular, such as a rear mounted radiator and tempered glass side panel, you have the makings for a great case. That said, what is the 101C like to build in, and what kind of hardware can you fit in this mid-tower chassis? Let’s take a look at the hardware we were able to cram into the In Win 101C.

Specifications

In Win 101c

Model 101C
Colors Black, White
Case Type Mid Tower
Material SECC, ABS, PC, Tempered Glass
M/B Compatibility ATX, Micro-ATX, Mini-ITX, Max: 12″ x 10.5″
Expansion Slots PCI-E x 7
Maximum Compatibility VGA Card Length: 421mm (Maximum)
VGA Card Length: 305mm (With Side Radiator)
CPU Heatsink Height: 160mm
Front Ports 1 X USB 3.1 Gen 2 Type-C
2 x USB 3.0
HD Audio
Internal Drive Bays 2 x 3.5″
2 x 2.5″
(or 4 x 2.5 “)
Thermal Solution Compatibility 1 x 120mm Rear Fan / 120 mm Radiator
2 x 120mm Side Fan / 240mm Radiator
3 x 120mm Bottom Fan / 360mm Radiator
Power Supply Compatibility PSII: ATX12V
– Length up to 200mm
Product Dimension
(H x W x D)
445 x 220 x 480 mm (17.5″ x 8.7″ x 18.9″)
Product Dimension
(H x W x D)
with screw & handle height
445 x 226 x 480 mm (17.5″ x 8.7″ x 18.9″)
Package Dimension
(H x W x D)
532 x 282 x 506mm (20.9″ x 11.1″ x 19.9″)
Net Weight 7.45
Gross Weight 8.66



Polaris Fans

Related Articles
Product Name Polaris RGB
Part Number Single Pack POLARISFAN-1PK-RGB
Twin Pack POLARISFAN-2PK-RGB
Fan Size 120 x 120 x 25mm
Material PBT, PC
Starting Voltage 5V
Fan Rated Voltage 12V
Fan Rated Power 1.2W
Fan Rated Current 0.10A
RGB LED Rated Voltage 12V
RGB LED Rated Power 1.2W
RGB LED Rated Current 0.10A
Speed Mode 500~1280R.P.M
Air Flow 43.31CFM
Air Pressure 1.26mm-H2O
Fan Connector 8-Pin Modular
Noise Level 20.2dB(A)
Bearing Type Sleeve Bearing
Life Expectation 35,000 hrs / 25℃
Net Weight 362g (2 Pack) / 178g (1 Pack)
Package Dimension
(H x W x D)
185mm x 125mm x 53mm (2 Pack)
185mm x 125mm x 30mm (1 Pack)
Warranty 2 years
