Cooler Master MasterLiquid Pro Series AiO Launched



Cooler Master has been busy streamlining their products over the past year but they have also made big changes to their all-in-one watercooling line, introducing the new Cooler Master MasterLiquid Pro Series  AiO CPU coolers. The new CPU cooler series will be available in 120, 140, 240, as well as 280 radiator sizes and will feature a new dual-chamber pump where heat is more isolated from the core chamber unlike current AiO pump-block designs. Modders-Inc’s will be testing the new AiO series itself once our sample arrives to see how it stacks up but it looks very promising so far considering how well previous CM AiO coolers have fared previously.  In terms of pricing, the MasterLiquid Pro Series 240 will be priced at $119.99 while the MasterLiquid Pro 120 will have a $99 MSRP.

masterliquidprodualchamber

Cooler Master Case Compatibilty Chart:

MasterLiquid Pro 240 MasterLiquid Pro 120
MasterCase Pro 5 Yes Yes
MasterCase 5 Yes Yes
Cosmos II Yes Yes
Stryker Yes Yes
Trooper Yes Yes
Scout II No Yes
HAF X Yes Yes
HAF 912 No Yes
HAF XB Evo Yes Yes
Elite 110 No Yes
Elite 130 No Yes
N200 Yes Yes
N400 Yes Yes
Silenctio 652 Yes Yes

Cooler Master MasterLiquid Pro

Specifications:

MasterLiquid Pro 240 MasterLiquid Pro 120
Dimension (L x W x H) 94.8 x 68 x 56.9 mm (3.7 x 2.68 x 2.2 inch) 94.8 x 68 x 56.9 mm (3.7 x 2.68 x 2.2 inch)
Radiator Dimension 275 x 118.5 x 27 mm (10.83 x 4.67 x 1.06 inch) 145 x 118.5 x 38 mm (5.71 x 4.67 x 1.50 inch)
Radiator Material Aluminum Aluminum
Fan Dimension 120 x 120 x 25 mm (4.7 x 4.7 x 1 inch) 120 x 120 x 25 mm (4.7 x 4.7 x 1 inch)
Fan Speed 500 ~ 2000RPM 500 ~ 2000 RPM
Fan Air Flow 66.7 CFM ± 10% (113.32 m3/h ± 10%) 66.7 CFM ± 10% (113.32 m3/h ± 10%)
Fan Air Pressure 2.34 mm H2O ± 10% 2.34 mm H2O ± 10%
Fan Life Expectancy 160,000 hours 160,000 hours
Noise Level(dB-A) 6 – 30 6 – 30
Fan Bearing Type POM POM
Fan Connector 4-pin 4-pin
Rated Voltage 12 VDC 12 VDC
Pump Life Expectancy 70,000 hours (L10) 70,000 hours (L10)
Pump Noise Level(dB-A) <12 <12
Pump Rated Voltage 12 VDC 12 VDC
Pump Power 6.0W 6.0W

Source: Press Release

Related Articles

Cooler Master Launches Liquid Cooling Solution: MasterLiquid Pro Series

Introducing MasterLiquid Series: MasterLiquid Pro 120 | 140 | 240 | 280 – All-In-One (AIO) Liquid Cooler with Dual Chamber Design

Chino, USA – Cooler Master, a leader in design and innovation of computer components and peripherals, today launched the MasterLiquid Pro Series; four all-in-one liquid cooling solutions designed for those who want to push their systems harder. The MasterLiquid Pro comes in four different sizes perfect for the needs of gamers, modders, designers, and overclockers.

“The MasterLiquid Pro comes with FlowOp Technology. Simply put – we have optimized the flow inside the liquid cooler. FlowOp looks at the flow of heat as it is carried and dissipated by an all-in-one (AIO) liquid cooler. Starting with the hot CPU, we reengineered how liquid absorbs and expels that heat,” said Richard Chen, Thermal Product Manager. “Our holistic approach to the flow of heat puts in your hands a comprehensive cooling machine that lasts longer, performs better and requires virtually no maintenance.”

FlowOp Technology: Holistic Approach to Cooling with Dual Chamber Design: Most AIO liquid coolers try to “carry away” the heat generated from the CPU by flowing water over the copper base and the aluminum fins attached to it. When the coolant runs through these dense fins, it slows down. Cooler Master has stacked an extra chamber on top and engineered it so that when cold stuff goes in, hot stuff does not come back up. The cooler upper chamber is where all of the vital components are placed ensuring a longer lifetime for the integral components in the design.

Customized Water Block and Pump Design Ensures Heat Leaves your Case: Using technology from top-end DIY liquid cooling kits to develop a powerful pump that sprays liquid directly at the center of the water block solves the issue of slow flow. This also allows mounting even more ultra-fine fins on the copper base, creating more surfaces from which the coolant can take away heat. Once heat is carried out and channeled past the radiator fins, the fins become the deciding factor in whether heat leaves your case.

Increased Performance with Unique Square Fin Design and MasterFan Pro Air Balance: The MasterLiquid’s unique square fin design creates greater surface area for absorption of the heat and allows for spacious airflow. The increased space allows for the installation of the all-new MasterFan Pro Air Balance fans, that pushes air farther out of the case for a silent cooling option. Quieter than high static pressure fans they last just as long as the liquid cooler.

Cooler Master MasterLiquid Pro

Whisper Quiet Operation with Silent Driver IC and Thermal Grease Support: Adding to that effort towards silence, Cooler Master encased the pump needed to drive the concentrated spray at the CPU with a silent driver. The custom driver rotates more smoothly, reducing noisy clicks and vibration. Each MasterLiquid Pro comes with the all new MasterGel Pro thermal grease to deliver an even better performance.

Availability:

MasterLiquid Pro 120 – April 2016

MasterLiquid Pro 140 – May 2016

MasterLiquid Pro 240 – April 2016

MasterLiquid Pro 280 – May 2016
